GTFS Source: Latest Vancouver GTFS-Static Data

Trip Filters:

Route Type: Route Type Typically has the following nomenclature:
1 = Subway/Metro
2 = Rail
3 = Bus
4 = Ferry
MultiSelect is available

Route Name: Route Name is the name of the route, such as "Red Line" or "180".
MultiSelect is available

Service Pattern ID: Service Pattern ID is a unique identifier for the service pattern defined in the Calendar or Calendar_date file.
MultiSelect is available

Service-Date: Select a specific date or a generic weekday to filter trips by service availability.

Cluster Stops?

0%

Animation Controls

Speed: 00:00:00

? The headway is estimated by the number of trips scheduled in this hour. If the route contains multiple patterns with different lengths, they are weighted to the most common trip pattern. For example, if the most common trip pattern of the route is 30 km, a 60 km trip would count as 2 trips in estimating the line headway.

Service-Date 1: Service-Date 2:

Base shape:

Select one route pattern to build a static scheduled time-distance diagram.

No shape selected yet.

Transit Accessibility Score

Click a location on the map

The score reflects how easy it is to access frequent transit from this spot. This feature was made for fun and there's no research-proven formula behind it! The scoring considers distance to services, number of routes, and service frequency

Help & Instructions

Welcome to Transit Bunny!

A tool that lets you unpack GTFS transit schedule.

Loading Data

The page starts by default with the latest Vancouver (TransLink) GTFS dataset
To load your own data to explore: click Load My Own GTFS ZIP. Nearly all transit agencies publish their gtfs on the web as a zip file, and usually this zip file can be used directly here. The zip file should contain the typical GTFS files including:

routes.txt
trips.txt
shapes.txt
stop_times.txt
etc.

Trip Filters

Use Route Type, Route Name, and Service/Date to limit which trips are shown and animated.
Multi-select is supported — pick up to two service-dates for side-by-side comparison.
[Optional] Click Update Map after changing filters to refresh stops and route shapes.

Animation

Open Animation (ribbon) to access playback controls: Play, Pause/Resume, Stop and Speed.

Graphs

There are 3 plots available: number of vehicles over time, vehicle‑kilometers, and headways.
Graphs update in sync with animation progress [i.e. a complete graph requires a complete animation]

Statistics

Generate route-specific statistics, or compare service dates to see their difference
This could be helpful for analyzing the magnitude of service changes between two dates!

Transit Score

Click any map location to compute an accessibility score
This score is an approximation intended for quick exploration and not a formal metric!

📝 See ChangeLog

Want more features or help? Contact me (Luke Li) on LinkedIn.
